Verifying Dimensional Accuracy

Dimensional inspection is performed to verify the accuracy of product features usually during product development or following production. Projects Inc. gives customers the measurement information they need for product verification and quality control.

Our conventional measuring equipment includes thread, plug and height gages, micrometers, calipers and surface plates. The inspectors at Projects Inc are also thoroughly trained to interpret customer prints and use CMM technology for timely, reliable and repeatable dimensional inspection measurements.

For the highest degree of accuracy, we minimize factors that contribute to measurement uncertainty. At Projects Inc., dimensional inspection is performed in an environmentally-controlled laboratory with regulated temperature and humidity.

Projects Inc.performs dimensional inspection on surface and specialty features of machined parts and products, including internal and external fastener threads. First-article per AS9102 using SolidWorks Inspection Software.

• Dimensional inspections are done using our two Mitutoyo contact CMM’s using MCOSMOS software
• Conventional inspection using thread gages, plug gages, height gages, micrometers, calipers and surface plates.
